Operation System
- OSAndroid 10
- GMS certifiedYES
- CPUQcta-core 2.3 GHz, Qualcomm 720G (SM7125)
- Memory4GB RAM / 64GB Flash
- Languages supportMulti-languages
Display
- Screen Size4”TFT-LCD WVGA (480x800) color screen (400 nits)
- TouchpanelUltra-sensitive capacitive touch screen, compatible
with gloves and support wet resistance
Buttons / Keypad
- Buttons / KeypadNumeric (29 keys)/ Function Numeric (38 keys) with backlight
Camera
- CameraRear 13 MP Autofocus with flash
Indicator Type
- TypeLED, Speaker, Vibrator
Symbologies
- 1D BarcodesUPC/EAN/JAN, GS1 DataBar, Code 39, Code
128, Code 32, Code 93, Codabar/NW7, Interleaved 2
of 5, Matrix 2 of 5, MSI, Trioptic
- 2D BarcodesPDF417, MicroPDF417, GS1 Composite ,
Code11, Aztec Code, Data Matrix, QR Code, Micro
QR Code, MaxiCode, Han Xin Code, DOT Code
Postal : Intelligent Mail Barcode, Postal-4i, Australian
Post, Japanese Post, Netherlands (KIX) Post,
Postnet, Planet Code
OCR : OCR-A, OCR-B, E13B (MICR)
RFID
- HF RFIDSupport HF/NFC
Frequency 13.56Mhz
Support: ISO14443A/B, ISO15693 standard
Communication
- Bluetooth®Bluetooth® 5.1
- WLAN802.11a/b/g/n, 802.11ax-ready, 802.11ac Wave 2(Dual
Antenna, MU-MIMO 2X2 support)
- WWANLTE Advanced Support Up to CAT4 LTE downlink
300Mbps/uplink 100Mbps
LTE (FDD) – Bands 1, 2, 3, 4, 5, 7, 8, 17, 20, 28
LTE (TDD) – Bands 38, 39, 40, 41
UMTS/HSPA+ (3G) – Bands 1, 2, 5, 8
GSM/GPRS/EDGE Quad-Band (850/900/1800/1900 MHz)
- GPSGPS, GLONASS, Galileo, BeiDou
- SensorsGyroscope, G-sensor, E-compass, Light & Proximity Sensor
I/O Interfaces
- USBUSB 3.1 (type-C) support USB OTG
Support Display Port Mode
Ethernet/USB-Host via cradle
- OTGYes, over USB Type-C
- POGO PINCustom IO connector (include USB Host)
- SIM SlotNano SIM Slot x 2
- Expansion SlotMicro SD/TF x 1(Support SD, SDHC and SDXC)
- Audio2W output ,105 dB at 10cm, Dual-Microphone, support
noise cancellation
Enclosure
- Dimensions ( W x D x H )195 mm x 72 mm x 34 mm
- Weight395g(with battery)
Durability
- Drop Specification1.8 m / 2.4 m(with Bumper)
- SealingIP67
Environmental
- Operating temperature-20°C to +50°C
- Storage temperature- 30°C to 70°C (without battery)
- Charging temperature0°C to 45°C
- Relative Humidity5% ~ 95% (non-condensing)
Power Source
- Main batteryMain battery 3.7V 6700mAh
- Hot SwapKeeps applications active up to 1 minute
Software
- MDM SoftwareSOTI, Ivanti Wavelink, AirWatch, 42Gears, and MoboLink
Regulatory Approvals
- Regulatory ApprovalsCE, FCC, NCC, IC, VCCI, TELEC, CCC, SRRC, RoHS, CEC, BQB, GMS, N-Mark
Accessories
- USB Type C cable
- Single Slot Charging cradle
- Single Slot Ethernet cradle with USB host
- 4-Slot Charging cradle
- 4-Slot Ethernet cradle
- 4-Slot battery charger
- Hand strap
- Glass Screen Protector
|
