| Operating System |
Windows 10 Pro |
| |
______________________________ |
| Mobile Computing Platform |
Intel® Core™ i5-7440EQ 2.9GHz
Max. 3.6GHz
- 6MB Intel® Smart Cache
Platform options:
Intel® Core™ i7-7820EQ 3.0GHz
Max. 3.7GHz
- 8MB Intel® Smart Cache |
| |
______________________________ |
| VGA Controller |
Intel® HD Graphics 630
Optional: NVIDIA® GeForce® GTX1050 4GB discrete graphics controller
Optional: NVIDIA® Quadro® P2000 4GB discrete graphics controller |
| |
______________________________ |
| Display |
15.6" TFT LCD FHD (1920 x 1080)
Protection film
1,000 nits QuadraClear® sunlight readable display
Optional: Resistive touch screen |
| |
______________________________ |
| Storage & Memory |
8GB DDR4
Optional: 16GB / 32GB / 64GB DDR4 i
500GB SATA HDD / 512GB SATA SSD
Optional: 1TB SATA HDD / 1TB / SSD |
| |
______________________________ |
| Keyboard |
LED backlit membrane keyboard with integrated numeric keypad
Optional: LED backlit rubber keyboard |
| |
______________________________ |
| Pointing Device |
Touchscreen
- Optional: Pressure sensitive touchscreen
Touchpad
- Glide touchpad with scroll bar |
| |
______________________________ |
Expansion Slots
(Will have same disclaimer number and Dimensions
(disclaimer number vary from model to model) |
Smart card reader x 1
ExpressCard/54 x 1
Optional: PCMCIA Type II x 1
Without SD Card Reader starting March 5th, 2021 |
| |
______________________________ |
| Multimedia Bay |
DVD super multi drive
Optional 2nd storage: 500GB HDD / 1TB HDD / 512GB SSD / 1TB SSD
Optional 2nd battery: 10.8V, 9240mAh, 99.8Wh |
| |
______________________________ |
| I/O Interface |
Audio input (Mini-jack) x 1
Audio output (Mini-jack) x 1
DC in Jack x 1
USB 3.2 Gen 1 Type-A x 4
LAN (RJ45) x 2
HDMI x 1
Docking connector x 1
External VGA (15-pin; D-sub) x 1
Serial port (9-pin; D-sub) x 2
Optional: FHD webcam x 1
Optional: RF antenna pass-through for GPS ii, and WLAN |
| |
______________________________ |
| Communication Interface |
10/100/1000 base-T Ethernet
Intel® Dual Band Wireless-AC 8265, 802.11ac
Bluetooth (v4.2) iii
Optional: Dedicated GPS |
| |
______________________________ |
| Pre-installed Software |
Getac Utility
Getac Geolocation
Optional: Absolute Persistence® |
| |
______________________________ |
| Security Features |
TPM 2.0
Kensington lock
Intel® vPro™ Technology
Smart card reader |
| |
______________________________ |
| Power |
AC adapter (150W, 100-240VAC, 50/60Hz)
Li-ion smart battery (10.8V, 9240mAh, 99.8Wh)
Optional: Multimedia bay 2nd Li-ion smart battery (10.8V, 9240mAh, 99.8Wh) |
| |
______________________________ |
| Dimension (W x D x H) & Weight |
410 x 320 x 65mm (16.1" x 12.6" x 2.5")
5.2 kg (11.4 lbs) iv |
| |
______________________________ |
| Rugged Features |
MIL-STD-810H certified
IP65 certified
MIL-STD-461G certified v
Vibration & drop resistant
Full magnesium alloy case
Shock-protected removable HDD
Optional: ANSI/UL 121201, CSA C22.2 NO. 213 (Class I, Division 2, Groups A, B, C, D) vi |
| |
______________________________ |
| Environmental Specifications |
Temperature vii:
- Operating: -20°C to 55°C / -4°F to 131°F
- Storage: -40°C to 71°C / -40°F to 160°F
Humidity:
- 95% RH, non-condensing |
| |
______________________________ |
| Accessories |
Battery (10.8V, 9240mAh, 99.8Wh)
AC adapter (150W, 100-240VAC)
Optional:
Backpack
Battery (10.8V, 9240mAh, 99.8Wh)
Multimedia bay 2nd HDD
Multimedia bay 2nd battery (10.8V, 9240mAh, 99.8Wh)
Multi-Bay charger (Dual-Bay)
AC adapter (150W, 100-240VAC)
Office dock AC adapter (150W, 100-240VAC)
MIL-STD-461 certified AC adapter (150W, 100-240VAC)
Stylus
Protection film
PCI or PCI-Express 3.0 expansion unit (x2 slots) viii
Vehicle dock viii
Office dock |
| |
______________________________ |
| Bumper-to-Bumper Warranty |
Accidents can take your equipment out of service when you least expect it, especially in a rugged environment, which can cause costly equipment downtime.
That is why Getac has introduced accidental damage as standard under our Bumper-to-Bumper warranty, to help minimize your enterprise IT costs.
Bumper-to-Bumper is your hassle-free guarantee. That means you can depend on us to have your unit back in service within days.
Standard
5 years Bumper-to-Bumper |
